Electrical Cable Damage Degree Test Apparatus for Conductor Integrity & Insulation Evaluation

Electrical Cable Damage Degree Test Apparatus for Conductor Integrity & Insulation Evaluation

Nama merek:	HongCe
Nomor Model:	HC9903B
Moq:	1 Set
harga:	Negotiatable
Ketentuan Pembayaran:	T/T,L/C
Kemampuan Penyediaan:	10 set per bulan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Sertifikasi:

TUV、ITS、CSA、BV、SGS 、CNAS(cost additional)

Spesialisasi Perusahaan:

Memproduksi beragam peralatan inspeksi

Sesuai standar:

UL486A-B, UL498

beban penyeimbang:

0,7-45,4kg dua set

Kinerja Penjualan:

Kinerja penjualan yang luar biasa baik di dalam maupun luar negeri

Bobot:

0,7, 0,9, 1,4, 2,3, 3,6, 4,5, 6,8, 11,4, 13,6, 18,2, 22,7, 27,2, 36,3, 45,4kg

Tingkat Uji:

9±1 RPM

Ketinggian uji:

250 ~ 500mm

Jumlah percobaan:

0-9999 kali, dapat diatur sebelumnya

Kemasan rincian:

Kayu lapis

Menyoroti:

cable damage test apparatus for conductors

electrical cable insulation evaluation equipment

conductor integrity testing device with warranty

Deskripsi Produk

Electrical Cable Damage Degree Test Apparatus

Precision testing equipment for evaluating conductor integrity and insulation performance after mechanical stress. Manufactured by HongCe, this apparatus delivers repeatable, standard-compliant results for laboratories, certification bodies, and cable manufacturers focused on product safety and long-term reliability.

Key Features

Precision mechanical structure ensures stable and repeatable damage simulation
Accurate assessment of conductor damage degree and insulation integrity
Compatible with various cable diameters and constructions
Smooth operation with minimal mechanical loss
High-strength materials for extended service life
Easy specimen installation and removal process

Technical Specifications

Test Height	250~500mm
Test Rate	9±1 RPM
Diameter of Gyration	76mm
Number of Trials	0-9999 times, programmable preset
Counterweights	0.7, 0.9, 1.4, 2.3, 3.6, 4.5, 6.8, 11.4, 13.6, 18.2, 22.7, 27.2, 36.3, 45.4kg (Two Sets)
Driving Method	Motor
Standards Compliant	UL486A-B, UL498

International Standards Compliance

UL 486A-B - Wire Connectors – Mechanical Strength and Damage Evaluation
IEC 60227 / IEC 60245 - Polyvinyl chloride and rubber insulated cables
IEC 60811 - Common test methods for insulating and sheathing materials
ISO 6722 - Road vehicles – Single-core cables

Equipment Overview

Frequently Asked Questions

Is this apparatus suitable for different cable standards?

Yes. The apparatus is designed to meet multiple international standards and can be customized for specific test clauses.

Can the equipment test automotive cables?

Yes. It is suitable for automotive electrical cables and wiring harness conductors.

Is customization available?

Absolutely. HongCe supports customized fixtures, stroke ranges, and test parameters.

Is calibration required?

Routine inspection is recommended to ensure long-term accuracy.

Do you provide technical training?

Yes. Operation guidance and technical support are provided.

Manufacturer: Guangzhou HongCe Equipment Co., Ltd.
Location: Guangdong, China
After-sales Service: Global support with fast and efficient service teams
