ISO 9906 Dual-Station Pump Performance Test System with PC/PLC Control

Iso 9906-Compliant Dual-Station Pump Comprehensive Performance Test System Pc + Plc/Dcs Integrated Control

Product Introduction
WPT-11 Dual-station Pump Comprehensive Performance Test System is committed to providing a one-stop, efficient pump performance verification solution.

• Product Description: The WPT-11 system is an advanced pump comprehensive performance test equipment. Its core advantage lies in the innovative dual-station design, which allows two pumps to be tested in parallel, greatly shortening the test cycle. The system is equipped with high-precision sensors that can measure the key performance parameters of the pump under different operating conditions in real time and accurately, and display, analyze and generate reports through an intuitive software interface. The rugged and durable structural design and user-friendly operation interface make it a powerful tool for daily testing and in-depth performance analysis.
• Product Use: WWPT-11 is widely used in pump R&D design verification, production line product quality control, new product type testing, factory performance acceptance testing, and teaching and research in scientific research institutions. It helps users comprehensively evaluate the hydraulic performance, mechanical performance and operating stability of the pump, ensure that the product meets the design requirements and international standards, thereby improving product competitiveness and reducing after-sales risks.

Product highlights

• Double-station parallel testing, double efficiency: The original double-station design can test two water pumps at the same time, greatly improving the test efficiency and shortening the product launch cycle.
• High-precision data acquisition, reliable results: The industry-leading high-precision flowmeter, pressure sensor, torque sensor, etc. are used to ensure the accuracy and repeatability of all test data.
• Automated intelligent control, easy operation: Equipped with advanced PLC/industrial computer control system, the test process is automated, from parameter setting to data collection and report generation, one-click completion, reducing the difficulty of operation.
• Comprehensive performance analysis, optimized design: Provide detailed water pump performance curves (Q-H, Q-P, Q-η, Q-NPSH), efficiency maps and cavitation characteristics analysis, providing a scientific basis for product optimization and improvement.
• Comply with international standards and globally recognized: The system design and test methods strictly follow international authoritative standards such as ISO 9906 to ensure the international applicability and authority of the test results.
• Modular design, flexible configuration: The system supports customized configuration and can be flexibly adjusted and expanded according to the specific test needs of customers (such as test flow, head range, additional test functions).
• Real-time monitoring and visual reporting: All test parameters are displayed in real time, and test reports that meet the specifications can be automatically generated. Data export and printing are supported for easy archiving and analysis.

International reference standards
The WPT-11 dual-station pump comprehensive performance test system strictly follows and supports the following major international pump test standards to ensure the international compatibility and compliance of test results:

• ISO 9906:2012: "Rotor Dynamic Pumps-Hydraulic Performance Acceptance Test-Accuracy Levels 1, 2 and 3". This standard specifies in detail the hydraulic performance acceptance test methods, test conditions, measuring instrument accuracy requirements, test result evaluation methods and accuracy level divisions for various types of rotor dynamic pumps (including centrifugal pumps, mixed flow pumps, and axial flow pumps). WPT-11 can support tests that meet its specified accuracy levels.
• ANSI/HI 1.6-2000: American National Standard Rotordynamic (Centrifugal) Pump Tests. This standard is an industry specification for centrifugal pump performance testing issued by the American Hydraulic Institute, covering the performance test procedures and methods of pumps. The design of WPT-11 fully considers compatibility with this standard.
• GB/T 3216-2005: Rotordynamic Pump Hydraulic Performance Acceptance Test Level 1 and Level 2. This is a Chinese national standard that is highly consistent with ISO 9906 and specifies the accuracy level and test requirements for the rotordynamic pump hydraulic performance acceptance test.
• IEC 60034-1: Rotating Electric Machines Part 1: Ratings and Performance. This standard applies to the motor part that drives the water pump. WPT-11 also considers the electrical parameter test and efficiency evaluation of the motor part when testing the overall performance of the water pump, which meets the relevant requirements.

Technical Parameters

After-sales service

We are well aware of the importance of high-quality after-sales service to customers. To ensure that your WPT-11 dual-station pump comprehensive performance test system can operate stably and efficiently for a long time, we provide a full range of professional services and support:

• On-site installation and commissioning: Our team of professional engineers will be on-site to be responsible for the installation, calibration and initial operation commissioning of the equipment to ensure that the system is seamlessly integrated and put into use.
• Operation and maintenance training: Provide targeted operation training courses to ensure that your technicians can master the daily operation, data analysis, basic maintenance and troubleshooting of the system.
• Technical support and remote assistance: Set up a dedicated technical support team to provide customers with timely responsive technical consultation and fault diagnosis services through various means such as telephone, email or remote assistance.
• Regular maintenance and calibration: Provide regular on-site maintenance and instrument calibration services to ensure that the system measurement accuracy always meets international standards and extend the service life of the equipment.
• Spare parts supply: Establish a complete spare parts inventory system to ensure the timely supply of key components and minimize downtime caused by spare parts problems.
• Software upgrades and updates: Regularly release system software updates and upgrade packages to provide new features and optimize performance to ensure that your system always stays at the forefront.
• Warranty: Provide comprehensive warranty services, covering equipment parts and labor, so you have no worries.
